ULTRASONIC ECHO SOUNDER (200 KHZ)
|USEABLE FREQUENCY RANGE 3DB FROM FR||180 kHz – 220 kHz|
|OPEN CIRCUIT VOLTAGE OCV||-195 dB re 1 V/µPa|
BEAM ANGLE AXIAL 3DB AT FR
TRANSMIT VOLTAGE RESPONSE TVR
140 dB re 1 µPa/V @ 1m
The SX20-02 is an ultrasonic echo sounder. It operates at 200 kHz, a frequency typical of fish finding applications. The mounting flange and connector were selected to meet a customer specification. They can easily be customized to your requirements. The operating frequency can also be modified.
